Promax ATLAS NG Broadcast Analyzer (DVB and ATSC 3.0)
Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk
ATLAS NG is a multipurpose NextGen TV ATSC 3.0 and DVB analyzer which includes 5G and covers the most stringent requirements for broadcast professionals. DVB-S2x, IPTV, Fiber optics, 3G-SDI, Transport stream ASI, Wi-Fi, OTT… all checked!
- DVB-S2x, DVB-S2/T2/C2, ISDB-T and ATSC 3.0
- 6 GHz frequency range
- 4K UHD video demodulation
- SDI input
- Fiber optics, IPTV, OTT, WiFi...
- 10" multitouch screen
- Spectrum Analyzer
- TV Analyzer
- IPTV Analyzer
- ASI Analyzer
- SDI Analyzer
- WiFi Analyzer
- OTT Analyzer
- Ethernet Tester
Discover the possibilities
More information
Description
Promax ATLAS NG Universal Broadcast Analyzer (DVB and ATSC 3.0)
The Promax ATLAS NG Universal Broadcast Analyzer is a broadcast spectrum analyzer capable of taking measurements up to 6 GHz covering the S and C bands, where an increasing number of technologies are all fiercely competing for bandwidth. It includes the latest broadcast technologies such as ATSC 3.0 and DVB-S2x in addition to 5G interference detection.It includes a 3G-SDI input to run a full 3G-SDI signal diagnosis, including a professional audio meter and eye diagram, and features an external SDI input for that task, other than the standard ASI input and output.
The built-in IPTV analyzer is able to analyze up to 4 IPTV streams simultaneously. The omnipresence of IP technology in the broadcast industry makes it compulsory for an analyzer to be capable of feeding from IPTV signals and monitor them. The flexibility of IPTV allows to flood a network with multiple streams. Therefore, it becomes essential to have at hand a tester that can monitor and picture several IPTV streams simultaneously.
The new multitouch user interface based on customizable docking pannels ensures an improved user experience. The analyzer is easier to use than ever before!
The Promax ATLAS NG Universal Broadcast Analyzer
For those who do not compromise and equip themselves with top-shelf test equipment only, we created ATLAS NG, a multipurpose and featured packed spectrum analyzer which covers the most stringent requirements for broadcast professionals. DVB-S2x, ATSC 3.0, IPTV, Fiber optics, 3G-SDI, Transport stream ASI, Wi-Fi, OTT… all checked!The new outer frame offers extreme ruggedness while featuring a larger 10” touch screen and maximizing grip and ease of handling.
DVB-S2x, ATSC3.0 and more...
The latest broadcast technologies: New television standards such as ATSC 3.0 push forward frontiers in what technology is capable of. ATSC 3.0 makes use of OFDM and as many as four simultaneous PLPs (Physical Layer Pipes) at the physical layer and modulation schemes up to 4096-QAM.DVB-S2x is the new kid on the block in satellite broadcast. It provides higher throughputs and new signal modulation schemes that only the most advanced broadcast analyzers such as the ATLAS NG can handle.
64/128/256-APSK modulations, 5%, 10% and 15% reduced roll-off factors, improved filtering and carrier spacing, and channel bonding are just some of the new technologies adopted by this new standard, and of course, ATLAS NG is fully compatible.
New more powerful 6 GHz Spectrum
Partner yourself with an analyzer capable of taking measurements up to 6 GHz covering the S and C bands, where an increasing number of technologies are all fiercely competing for bandwidth.Technologies using S and/or C band are: Satellite teleports, VSAT ground networks, Radar, Terrestrial microwave links, Broadband Wireless Access (BWA) networks (LTE, Wi-Max, 5G, etc.).
Applications: TV broadcast & data, Air avigation and maritime communications, Banking comms, E-government, Backhaul in remote areas or in mission-critical operations, Aircraft Radar altimeters, Weather/metereological stations, ITS (Intelligent Transport Systems), ISM (Industrial, Scientific and Medical), etc.
A 6 GHz spectrum analyzer becomes vital to identify and evaluate why systems and services are being disrupted by interferences.
All-In-One Multifunction Analyzer
Finding a meter that could close the gap between the studio and transmission departments has been a long time coming, but it is finally here.The Promax ATLAS NG Universal Broadcast Analyzer runs full 3G-SDI signal diagnosis, including a professional audio meter and eye diagram, and features an external SDI input for that task, other than the standard ASI input and output.
The omnipresence of IP technology in the broadcast industry makes it compulsory for an analyzer to be capable of feeding from IPTV signals and monitor them. The flexibility of IPTV allows to flood a network with multiple streams.
Therefore, it becomes essential to have at hand a tester that can monitor and picture several IPTV streams simultaneously.
