Pendulum A600 Single Channel High Voltage Linear Amplifier

Sale price0,00 DKK Price on quotation
Order Item

Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk

The Pendulum Instruments High Voltage Linear Amplifier A600 has a fixed amplification of 100 times and capable of bipolar high voltage output of ±300V. Any signal source with amplitude up to ±3 V can be used as an input device.  The input amplitude should normally be kept within ±3 V. The A600 High Voltage Linear Amplifier is equipped with a microfuse rated at 15 mA, which will be blown if the input voltage exceeds 500% of the maximum.

Discover the possibilities

More information

Pendulum A600 Single Channel High Voltage Linear Amplifier

The maximum capacitive load is set at the factory to 300 V/µs which yields the load limit of 300 pF. The continuous output current limit is 75 mA and the output power limit is ca 30 W.


FREQUENCY RESPONSE

Full and small-signal frequency responses without load (red and orange marks) and with 400 pF capacitive load (blue and green marks), respectively, are shown in the diagram below:
