Keithley 2614B SourceMeter
Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk
- Channels - 2
- Max Current Source/Measure Range - 10A
- Max Voltage Source/Measure Range - 200V
- Measurement Resolution (Current / Voltage) - 100fA / 100nV
- Power - 200 W
%20-%20100fA%20/%20100nV%0A%20%09Power%20-%20200%20W%0A
){kind=link}
Discover the possibilities
More information
Description
Keithley 2614B SourceMeter
Keithley’s Series 2600B System SMU instruments are the industry standard current-voltage source and measure solution for highly automated production test applications. Both dual- and single-channel models tightly integrate a precision power supply, true current source, DMM, and electronic load with pulse generating capabilities. Plus, TSP® technology runs complete test programs for automated system applications, and TSP-Link® technology enables daisy-chaining up to 64 channels for high volume parallel test.
Complete production test without sacrificing footprint
Meet all your production test needs with two completely isolated channels of wide dynamic source and measure within the same footprint. Each 40 W channel provides 6½-digit precision resolution source and measure from 10 A pulse to 0.1 fA and 200 V to 100 nV at less than 100 µs pulse width and within 0.1% of settled value.
Highlights
- Up to 2 channels in the same footprint
- Widest dynamic range of voltage and current
- Highly accurate 100 µs pulse expanding DC production test capabilities
Embedded scripting for unmatched production throughput
Meet all your production test needs with two completely isolated channels of wide dynamic source and measure within the same footprint. Each 40 W channel provides 6½-digit precision resolution source and measure from 10 A pulse to 0.1 fA and 200 V to 100 nV at less than 100 µs pulse width and within 0.1% of settled value.
Highlights
- Eliminates time-consuming bus communications to and from the PC
- Advanced data processing and flow control
- Versatile prober/handler control
System performance, without a mainframe
TSP-Link® technology enables expansion up to 64 channels for high-speed, SMU-per-pin parallel testing without a mainframe. All channels are simultaneously and independently controlled at a tight <500 ns.
Highlights
- Supports <500 ns channel-to-channel synchronization
- Up to 32 SMUs or 64 independent SMU channels
- Reconfigure easily as test requirements change
Best low current performance for production
The 2635B and 2636B SMUs provide 0.1 fA, 10-16 resolution on the lowest 100 pA range, reducing ultra-low level sample characterization worries and assuring production success.
Highlights
- 7x faster settling time on the lowest current range
- Best low current resolution on the market
- Direct triax connection simplifies setup
For more information: Tektronix
