Keithley 2260B-80-40 Programmable DC Power Supplies
Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk
- Max Output Power - 1080 W
- Maximum Voltage - 80 V
- Maximum Current - 40.5 A
- Connectivity - USB/LAN; GPIB optional
Discover the possibilities
More information
Description
Keithley 2260B-80-40 Programmable DC Power Supplies
Source a wide range of voltages and currents with the 360W, 720W, or 1080W Series 2260B Programmable DC Power Supplies. The 360W versions can output current of 36A, 13.5A, 4.5A, or 1.44A; the 720W models can output 72A, 27A, 9A, or 2.88A; and the 1080W instruments can output 108A, 40.5A, 13.5A or 4.32A. This wide range of output voltages and current, combined with multiple interface choices, makes the Series 2260B ideal for use in a wide range of applications, including research and design, quality control, and production test.
Features | Benefits |
| Programmable voltage or current rise and fall times from 0.1V/s to 1600V/s or 0.01A/s to 216A/s (model dependent) | Prevents damage from inrush current to loads that have low impedance when power is initially supplied. |
| Constant current priority setting | Reduces voltage and current overshoot when powering LEDs. |
| Programmable output resistance | Allows simulating a battery’s output characteristics. |
| Analog input control | Supports creating voltage profiles that simulate how a battery responds to a fast changing load current or generating a combined DC output level with an AC signal superimposed on it to test how a circuit responds to noise on its DC power source. |
| Internal test sequence mode | Allows outputting a set of voltage levels for varying time intervals at each level. The test sequence can be stored and used repeatedly to determine DUT performance at different levels. |
| Series or parallel configurable | Delivers up to 3240W when three units are combined in parallel. |
| Fast discharge capability and 1ms transient recovery time to load changes. | Minimizes test times in automated test systems. |
| Fit six 360W, three 720W, or two 1080W units in a standard rack width | Save bench and test system rack space. |
For more information: Tektronix
