Promax SATHUNTER+ DVB-S/S2 and DSS Satellite hunter
Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk
The SATHUNTER+ is an instrument designed for the installation of Direct To Home (DVB-S/S2 and DSS) satellite reception systems. It is fully automaticand very easy to use. Just turn the dish and the instrument will show up the identification of the selected satellite when it is detected. The instrument is actually reading the information transmitted by the satellite and displays its orbital position and the service list.
%20satellite%20reception%20systems.%20It%20is%20fully%20automaticand%20very%20easy%20to%20use.%20Just%20turn%20the%20dish%20and%20the...
){kind=link}
Discover the possibilities
More information
Description
Promax SATHUNTER+ DVB-S/S2 and DSS Satellite hunter
The SATHUNTER+ is an instrument designed for the installation of Direct To Home (DVB-S/S2) satellite reception systems. It is fully automatic and very easy to use. Just turn the dish and the instrument will show up the identification of the selected satellite when it is detected. The instrument is actually reading the information transmitted by the satellite and displays its orbital position and the service list.Specifications:
- 3-STEP PROCESS: Satellite detection, identification, fine adjust
- SATELLITES: 50 maximum
- SYMBOL RATE (DVB-S): 2 to 45 Mbauds
- SYMBOL RATE (DVB-S2): QPSK/8PSK: From 2 to 45 Mbauds
- SYMBOL RATE (DSS): 22 Mbauds
- BATTERIES: Long life Li-Ion batteries
- CONFIGURATION: Includes CD-ROM and USB cable to modify configuration
Selective identification:
The equipment can be programmed for a specific application, dish alignment for a specific satellite for instance . This could be the case of installers working for a particular DTH platform that want to eliminate any possibility of error and the related waste of time. Equipment settings can be modified at will using a PC computer and the supplied software.
Identification of up to 50 satellites:
In IDENTIFICATION (2) mode, the equipment reads the information it receives from the satellite, presenting the orbital position and name of the service or satellite for a maximum of 50 satellites that can be programmed as the user deems appropriate.
Detection of short circuits and protection:
The equipment allows detection of excessive LNB consumption. Outages in the cable or faulty LNB operation will be indicated by the equipment. It also has a short circuit detection feature.
Documents
Promax SATHUNTER+ DVB-S/S2 and DSS Satellite hunter
Promax SATHUNTER+ - DatasheetOptions
Video
Promax SATHUNTER+ DVB-S/S2 and DSS Satellite hunter
The SATHUNTER+ is an instrument designed for the installation of Direct To Home (DVB-S/S2) satellite reception systems. It is fully automatic and very easy to use. Just turn the dish and the instrument will show up the identification of the selected satellite when it is detected. The instrument is actually reading the information transmitted by the satellite and displays its orbital position and the service list.Specifications:
- 3-STEP PROCESS: Satellite detection, identification, fine adjust
- SATELLITES: 50 maximum
- SYMBOL RATE (DVB-S): 2 to 45 Mbauds
- SYMBOL RATE (DVB-S2): QPSK/8PSK: From 2 to 45 Mbauds
- SYMBOL RATE (DSS): 22 Mbauds
- BATTERIES: Long life Li-Ion batteries
- CONFIGURATION: Includes CD-ROM and USB cable to modify configuration
Selective identification:
The equipment can be programmed for a specific application, dish alignment for a specific satellite for instance . This could be the case of installers working for a particular DTH platform that want to eliminate any possibility of error and the related waste of time. Equipment settings can be modified at will using a PC computer and the supplied software.
Identification of up to 50 satellites:
In IDENTIFICATION (2) mode, the equipment reads the information it receives from the satellite, presenting the orbital position and name of the service or satellite for a maximum of 50 satellites that can be programmed as the user deems appropriate.
Detection of short circuits and protection:
The equipment allows detection of excessive LNB consumption. Outages in the cable or faulty LNB operation will be indicated by the equipment. It also has a short circuit detection feature.
