The Pendulum Instruments High Voltage High Current Linear Amplifier P100 has a fixed amplification of 10 times and capable of bipolar high voltage output of ±50V. Any signal source with amplitude up to ±10 V can be used as an input device. The input amplitude should normally be kept within ±10 V. The High Voltage High Current Linear Amplifier P100 is equipped with a microfuse rated at 15 mA, which will be blown if the input voltage exceeds 300% of the maximum.
Discover the possibilities
More information
Description
Pendulum P100 High Voltage High Current Linear Amplifier
The maximum capacitive load is set at the factory to 30 V/µs which yields the load limit of 200 nF. The continuous output current limit is 2 A and the output power limit is ca 128 W.
Frequency response
Full and small-signal frequency responses without load (blue and green marks) and with 100 nF capacitive load (red marks), respectively, are shown in the diagram below:
