Pendulum F20A Single Channel High Voltage Linear Amplifier
The maximum capacitive load is set at the factory to 400 V/µs which yields the load limit of 400 pF. The continuous output current limit is 185 mA and the output power limit is ca 30 W.
FREQUENCY RESPONSE
Full and small-signal frequency responses without load (red and orange marks) and with 400 pF capacitive load (blue and green marks), respectively, are shown in the diagram below:
