Keithley 2002 8½-digit DMM
Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk
- Maximum Resolution - 8.5
- Connectivity - GPIB
Discover the possibilities
More information
Description
The 8.5 digit Model 2002 High Performance Digital Multimeter not only delivers performance specifications usually associated only with instruments that cost thousands more, but it offers a broad range of functions not typically available from DMMs. With 1nV DCV sensitivity and a basic accuracy of 0.0006%, this DMM also offers 18 measurement functions. For greater flexibility a built-in card slot on the rear panel allows an additional multiplexer card for multi-point measurement applications. This DMM provides an excellent choice for production test, design verification, and metrology applications where high accuracy is critical.
Features | Benefits |
| True 8½-digit resolution based on 28-bit A/D converter | Provides greater dynamic range, avoiding range-shift errors and delays. |
Exceptional measurement integrity combined with high throughput | Tests precision components quickly and accurately in production environments. |
| Keysight 3458A emulation mode | Saves programming time within existing systems |
| Advanced AC measurements including Peak ACV, AC or AC+DC Coupling, RMS or average, and low frequency RMS | Reduces the number of instruments in your test system. |
| Multiple measurement display | Displays multiple measurements such as DC and AC volts and the AC frequency from a single measurement connection simultaneously Reducing the need for additional instruments. |
| Unique single-phase method for 4-wire ohms method | Allows measuring low resistances twice as fast. |
| Optional plug-in switch cards for multipoint measurements | Simplifies creating a self-contained, multipoint switch and measure solution. |
| Built-in bar graph display | Tracks reading trends around a target value easily saving time from off-line measurement analysis |
For more information: Tektronix
