High-Precision Data Acquisition – Save 20% Now!

Get 20% off the MR6000-01 Memory Recorder with our limited-time bundle MR6000-MAX. Realize accuracy, reliability, and efficiency in your data acquisition – with 1 TB storage capacity

MR6000-MAX Bundle: More Power for your DAQ

Build a powerful data acquisition setup and save 20% 1) with our limited-time bundle MR6000-MAX. The MR6000-MAX bundle includes the powerful MR6000-01 Memory Recorder, the U8335 1 TB SSD Unit, and the Z5021 Probe Power Unit providing a strong foundation for advanced data acquisition. The modular system can be further adapted with additional modules to meet your specific measurement requirements.

1) The 20% savings result from the MR6000-MAX bundle price compared to the list price of the MR6000-01 Memory Recorder, U8335 SSD Unit, and Z5021 Probe Power Unit. Modules and accessories are not included in this promotion, allowing you the flexibility to tailor your setup to your specific measurement needs. Only until 15th December 2026.

Take action now and elevate your measurement quality!​

The MR6000-01 Memory Recorder is a high-performance waveform recorder designed for capturing high-speed, high-accuracy data across multiple channels. Its modular design ensures versatility for various applications, while the 12.1-inch touchscreen and intuitive software provide optimum functionality and user experience.

• Up to 200 MS/s sampling
• 8 slots & up to 32 isolated channels
• Selection from 15 input and 3 output modules
• 12.1-inch capacitive touch screen for intuitive operation and enhanced analysis capabilities
• Real-time saving function for seamless, uninterrupted data capture


The U8335 SSD Unit is a high-performance storage solution tailored for uninterrupted, long-duration data acquisition. With its 1 TB capacity, it ensures long-term real-time saving at speeds as high as 20 MS/s. The recorded data remains uncompromised even if the device is powered off.

• 1 TB SSD for extended recording and secure storage
• Supports long-term data recording at high speeds of up to 20 MS/s


The Z5021 Probe Power Unit simplifies the integration of current sensors and differential probes by providing power to up to 8 current probes or differential probes directly. This reduces the complexity of your measurement setups significantly.

• Simplifies connections by eliminating the need for external power supplies.
• Powers up to 8 BNC current sensors or probes, streamlining setup.
• Enables compatibility with a wide range of HIOKI current clamps, e.g. CT67xx Series.
• Supplies power up to 8 differential probes (e.g. HIOKI 9322).

Real-time data saving ensures reliable data recording without the risk of losing any data, even for applications that require long-term measurements and the precision of the full data spectrum.

My Advantages

🌪️ Long-term recording with up to 20 MS/s
⌛ Extended recording durations, limited only by the storage capacity of the external device
💾 Record on the SSD, USB stick or choose any other device (via FTP)
⚡ Non-volatile memory guarantees data integrity and ensures that recorded data stays secure and ready for retrieval, even when the device is powered off

Input Modules

Combine up to 8 modules in total to achieve a powerful data recording setup, selecting from 15 input and 3 output modules to perfectly match your application needs

1. Voltage modules

Equip your Memory Recorder with your individual combination from a wide range of versatile input modules for precise voltage measurement. The MR6000 even offers options for high-speed, high-sensitivity, and high-voltage applications.

• U8976 - High-speed Analog Module: 2 ch., 200 MS/s, DC to 30 MHz, 12 bits, 400 VDC, BNC terminal
• U8974 - High-voltage Module: 2 ch., 1 MS/s, DC to 100 kHz, 16 bits, 1000 VDC, 700 VAC, banana input
• 8966 - Analog Module: 2 ch., 20 MS/s, DC to 5 MHz, 12 bits, 400 VDC, BNC terminal
• U8975 - 4 ch Analog Module: 4 ch., 5 MS/s, DC to 2 MHz, 16 bits, 200 VDC, BNC terminal
• U8978 - 4 ch Analog Module: 4 ch., 5 MS/s, DC to 2 MHz, 16 bits, 40 VDC, BNC terminal
• 8968 - High-resolution Module: 2 ch., 1 MS/s, DC to 100 kHz, 16 bits, 400 VDC, BNC terminal
• 8972 - DC/RMS Unit: 2 ch., 1 MS/s, DC to 400 kHz, 12 bits, 400 VDC, BNC terminal
• MR8990 - Digital Voltmeter Module: 2 ch., 2 ms, 24 bits, 500 VDC, banana input

2. Current measurement

For current measurement, HIOKI offers the dedicated U8977 Current Module. HIOKI current clamps and sensors with an ME15W connector connect directly to the module and are powered through it, while the MR6000-01 automatically recognizes connected sensors for faster setup and fewer configuration errors. With 3 channels, 5 MS/s sampling, DC to 2 MHz bandwidth, and 16-bit resolution, the U8977 enables high-performance current measurements and supports HIOKI’s broad current sensor portfolio. For added flexibility, the MR6000 can also be combined with analog input units and BNC current sensors, such as the CT671x Series, extending current measurement capabilities across a wider range of applications.

3. Other module types

In addition to voltage and current measurement, HIOKI offers a diverse range of input modules for various measurement items – from temperature and acceleration to strain, frequency, and more.

• 8967 - Temperature Module: 2 ch., 1.2 ms, 16 bits, push-button type terminal. For thermocouples K, J, E, T, N, R, S, W, B
• U8969 - Strain Module: 2 ch., 200 kS/s, DC to 20 kHz, 16 bits, NDIS connector EPRC07-R9FNDIS. For acceleration, load, pressure, or strain
• 8970 - Frequency Module: 2 ch., 200 kS/s, DC to 100 kHz, 400 VDC, 16 bits, BNC terminal. For frequency, rotation or pulse
• U8979 - Charge Module: 2 ch., 200 kS/s, DC to 50 kHz (DC), 1 Hz to 50 kHz (AC), 16 bits, BNC terminal. For acceleration (piezoelectric pickup) with built-in pre-amplifier
• 8973 - Logic Module: 4 probes / 16 ch., mini DIN connector. Compatible logic probes: 9320-01, 9327, 9321-01

Output Modules

The MR6000-01 Memory Recorder supports three output modules, including pulse and waveform generation for signal testing and simulation. These allow users to program and generate custom waveforms, ideal for reproducing and simulating anomalies. The free SF8000 software simplifies waveform creation by enabling direct data input or formula-based design and supports noise simulation or multiplying waveforms for advanced scenarios.

• U8793 - Arbitrary Waveform Generator Module: 2 ch., -10 V to +15 V, output frequency: 0 Hz to 100 kHz DC, Sine wave, Square wave, Pulse wave, Triangular wave, Ramp wave
• MR8790 - Waveform Generator Module: 2 ch., -10 V to +10 V, output frequency: 0 Hz to 20 kHz DC, Sine wave
• MR8791 - Pulse Generator Module: Pattern output: read frequency 0 Hz to 120 kHz, 2048 logic patterns. Pulse output: frequency 0 Hz to 20 kHz, duty 0.1% to 99.9%. Logic output: 0 V to 5 V. Open collector output
